OS-308F Alloy Steel Crane Tension Load Cell
OS-308F Alloy Steel Crane Tension Load Cell
OS-308F Alloy Steel Crane Tension Load Cell
  • OS-308F Alloy Steel Crane Tension Load Cell
  • OS-308F Alloy Steel Crane Tension Load Cell

OS-308F Alloy Steel Crane Tension Load Cell

S-type load cell


Inquiry

额定载荷 Rated Capacity

25/50/100/150/200/250 klb

精度等级 Accuracy Class

C3

灵敏度 Rated Output

2.0±0.1mv/v

非线性度Non-linearity

±0.02% F.S

蠕变 Creep(30min)

±0.02% F.S

输入阻抗Input Impedance

385±10Ω

输出阻抗Output Impedance

351±2Ω

工作温度Operation Temperature

-10~+40℃

安全过载 Safe overload

150%F.S

极限过载 Destructive Load

200%F.S

激励电压 Excitation Recommended

4~12VDC,  Max:15vDC

电缆结构 Cable

4芯电缆

4-wire with screen

Exc+(红 red),       Exc-(黑black)

Sig+(绿 green),Sig-(白white)

结构材质 Construction

材质为合金钢或不锈钢

Alloy Steel or Stainless steel, IP67

适用场合 Application for

各种吊秤和拉力测试场合

Crane,packing scale,tension etc.
